Automated Vehicle Door Panel Assembly Line

In the production workshop of an automotive parts factory, Foreman Jeo is facing a common industry challenge: manual assembly of car door panels is inefficient and difficult to maintain consistency, while the growing order demands are straining the traditional production model. The experienced workers need to repeatedly adjust the position of the door panels and manually tighten dozens of screws, which inevitably leads to deviations under high-intensity work—until the introduction of an automated door panel assembly line, which has resolved the dilemma of capacity and quality.

This intelligent production line, integrating four core processes, is redefining the standards for automotive interior manufacturing:

A Comprehensive Analysis of Automated Door Panel Assembly

Station 1: Vision-Guided Automatic Screw Tightening

As the door panel enters the first station, a high-resolution CCD camera instantly completes a 3D scan, accurately locating the coordinates of each screw hole. The data is transmitted in real-time to the robot control system, guiding the electric screwdriver to move precisely.

Station 2: Intelligent Thermal Riveting and Welding

When the door panel moves into the thermal riveting and welding station, the key lies in independent temperature control and precise pressure regulation. Each welding unit is equipped with a micro-heater and pressure sensors. The pneumatic positioning pins on the die-casting tooling start synchronously, lifting and locking the door panel to ensure zero displacement during the welding process.

Station 3: Robotic Flexible Clip Assembly

The station's highlight is vibration compensation and force-controlled grasping. The four-arm robot picks up clips from a vibrating feeder. Force sensors in the end-effectors provide real-time feedback, enabling adaptive grip adjustments. The process uses a "pre-alignment followed by vibration" strategy: clips are initially aligned with door panel slots via vision, then a 50-80Hz micro-vibration device activates, tapping the area with a rubber plate to embed clips. This technology resolves traditional assembly issues like misalignment and deformation.

Station 4: Full-Dimensional Quality Inspection

The quality of the door panel assembly is inspected through high-precision mechanical positioning and electronic detection technology, and the results are fed back.

Specification Parameters

After-sales Service Provided:

1.One-year warranty service

2.Online support, Video technical support
